  • MR104 bearing
Product name : MR104 bearing
Product No. : MR104 bearing 4x10x3 mm
←[Previous Product]              [Next Product]→
Details:


MR104 bearing has open, seals and shield types, and v-groove inner ring is available.

It widely used in precision instruments, micro motor, remote control model, etc industries.

Demesions:
Bearing No. MR104MR104-ZZ, MR104-2RS, MR104Z, MR104RS, MR104 ZZ, MR104 RS
Bore diameter (d) 4mm
Outer diameter (D) 10mm
Width (B) 3 mm
Basic Load Rating(N)
Dynamic(Cr) 604
Static(Cor) 218
Max. Speed(RPM)
Grease 48000
Oil 56000
Weight(g)
Approx. 0.96
Grade P0, P6, P5
Radial Clearance C0, C2, C3

 Technical Data:
Part number rule
Dimension Tolerance
Radial clearance
Vibration
Grease
