Product name : 629 ZZ/RS/OPEN
Product No. : Ball Bearing 629 9x26x8mm
Details:
629 bearing has open, seals and shield types, and v-groove inner ring is available.
It widely used in precision instruments, micro motor, remote control model, etc industries
Demesions: | |
Bearing No. | 629, 629-ZZ, 629-2RS, 629Z, 629RS, 629 ZZ, 629 RS |
Bore diameter (d) | 9 mm |
Outer diameter (D) | 26 mm |
Width (B) | 8 mm |
Basic Load Rating(N) | |
Dynamic(Cr) | 3879 |
Static(Cor) | 1586 |
Max. Speed(RPM) | |
Grease | 28000 |
Oil | 34000 |
Weight(g) | |
Approx. | 19 |
Grade | P0, P6, P5 |
Radial Clearance | C0, C2, C3 |
Technical Data:
Part number rule
Dimension Tolerance
Radial clearance
Vibration
Grease
