Product name : 606 ZZ/RS/OPEN
Product No. : Ball Bearing 606 6x17x6mm
Details:
606 bearing has open, seals and shield types, and v-groove inner ring is available.
It widely used in precision instruments, micro motor, remote control model, etc industries.
Demesions: | |
Bearing No. | 606, 606-ZZ, 606-2RS, 606Z, 606RS, 606 ZZ, 606 RS |
Bore diameter (d) | 6 mm |
Outer diameter (D) | 17 mm |
Width (B) | 6 mm |
Basic Load Rating(N) | |
Dynamic(Cr) | 1924 |
Static(Cor) | 677 |
Max. Speed(RPM) | |
Grease | 38000 |
Oil | 45000 |
Weight(g) | |
Approx. | 5.94 |
Grade | P0, P6, P5 |
Radial Clearance | C0, C2, C3 |
Technical Data:
Part number rule
Dimension Tolerance
Radial clearance
Vibration
Grease
