Product name : 699 ZZ/RS/OPEN
Product No. : Ball Bearing 699 9*20*6mm
Details:
699 bearing has open, seals and shield types, and v-groove inner ring is available.
It widely used in precision instruments, micro motor, remote control model, etc industries.
| Demesions: | |
| Bearing No. | 699, 699-ZZ, 699-2RS, 699Z, 699RS, 699ZZ, 699 RS |
| Bore diameter (d) | 9 mm |
| Outer diameter (D) | 20 mm |
| Width (B) | 6 mm |
| Basic Load Rating(N) | |
| Dynamic(Cr) | 2097 |
| Static(Cor) | 865 |
| Max. Speed(RPM) | |
| Grease | 34000 |
| Oil | 40000 |
| Weight(g) | |
| Approx. | 8.38 |
| Grade | P0, P6, P5 |
| Radial Clearance | C0, C2, C3 |
Technical Data:
Part number rule
Dimension Tolerance
Radial clearance
Vibration
Grease
