Product name : 694 ZZ/RS/OPEN
Product No. : Ball Bearing 694 4x11x4mm
Details:
694 bearing has open, seals and shield types, and v-groove inner ring is available.
It widely used in precision instruments, micro motor, remote control model, etc industries.
| Demesions: | |
| Bearing No. | 694, 694-ZZ, 694-2RS, 694Z, 694RS, 694 ZZ, 694 RS |
| Bore diameter (d) | 4 mm |
| Outer diameter (D) | 11 mm |
| Width (B) | 4 mm |
| Basic Load Rating(N) | |
| Dynamic(Cr) | 814 |
| Static(Cor) | 280 |
| Max. Speed(RPM) | |
| Grease | 48000 |
| Oil | 56000 |
| Weight(g) | |
| Approx. | 1.69 |
| Grade | P0, P6, P5 |
| Radial Clearance | C0, C2, C3 |
Technical Data:
Part number rule
Dimension Tolerance
Radial clearance
Vibration
Grease
