  • 635 ZZ/RS/OPEN
Product name : 635 ZZ/RS/OPEN
Product No. : Ball Bearing 635 5x19x6mm
←[Previous Product]              [Next Product]→
Details:


635 bearing has open, seals and shield types, and v-groove inner ring is available.

These miniature bearings have greatly wide range of applied fields including Skateboard, RC Car, Dental, Fishing Reel,Yoyo, Instrument, Electric Motor, Medical and so on.

Demesions:
Bearing No. 635, 635-ZZ, 635-2RS, 635Z, 635RS, 635 ZZ, 635 RS
Bore diameter (d) 5 mm
Outer diameter (D) 19 mm
Width (B) 6 mm
Basic Load Rating(N)
Dynamic(Cr) 1986
Static(Cor) 717
Max. Speed(RPM)
Grease 32000
Oil 40000
Weight(g)
Approx. 8.5
Grade P0, P6, P5
Radial Clearance C0, C2, C3

 Technical Data:
Part number rule
Dimension Tolerance
Radial clearance
Vibration
Grease
