  • 634 ZZ/RS/OPEN
Product name : 634 ZZ/RS/OPEN
Product No. : Ball Bearing 634 4x16x5mm
←[Previous Product]              [Next Product]→
Details:


634 bearing has open, seals and shield types, and v-groove inner ring is available.

These miniature bearings have greatly wide range of applied fields including Skateboard, RC Car, Dental, Fishing Reel,Yoyo, Instrument, Electric Motor, Medical and so on.

Demesions:
Bearing No. 634, 634-ZZ, 634-2RS, 634Z, 634RS, 634 ZZ, 634 RS
Bore diameter (d) 4 mm
Outer diameter (D) 16 mm
Width (B)  5mm
Basic Load Rating(N)
Dynamic(Cr) 1139
Static(Cor) 418
Max. Speed(RPM)
Grease 36000
Oil 43000
Weight(g)
Approx. 5.24
Grade P0, P6, P5
Radial Clearance C0, C2, C3

 Technical Data:
Part number rule
Dimension Tolerance
Radial clearance
Vibration
Grease
