  • R1810 bearings
Product name : R1810 bearings
Product No. : R1810 bearing
←[Previous Product]              [Next Product]→
Details:


R1810 bearing has open, seals and shield types, and v-groove inner ring is available.

It is widely used in Automotive, CNC Machinery, Textile Machinery, Washing Machine, Power Tool etc.

Demesions:
Bearing No. R1810 R1810-ZZ, R1810-2RS, R1810Z, R1810RS, R1810 ZZ, R1810RS
Bore diameter (d) 0.3125 inch
Outer diameter (D) 0.5000 inch
Width (B) 0.1562 inch
Basic Load Rating(N)
Dynamic(Cr) 104
Static(Cor)   50
Max. Speed(RPM)
Grease 40000
Oil 48000
Weight(g)
Approx. 1.39
Grade P0, P6, P5
Radial Clearance C0, C2, C3

 Technical Data:
Part number rule
Dimension Tolerance
Radial clearance
Vibration
Grease
