• 628 ZZ/RS/OPEN
Product name : 628 ZZ/RS/OPEN
Product No. : Ball Bearing 628 8x24x8mm
←[Previous Product]              [Next Product]→

628 bearing has open, seals and shield types, and v-groove inner ring is available.

It widely used in precision instruments, micro motor, remote control model, etc industries.

Bearing No. 628, 628-ZZ, 628-2RS, 628Z, 628RS, 628 ZZ, 628 RS
Bore diameter (d) 8 mm
Outer diameter (D) 24 mm
Width (B) 8 mm
Basic Load Rating(N)
Dynamic(Cr) 2833
Static(Cor) 1138
Max. Speed(RPM)
Grease 28000
Oil 34000
Approx. 17.1
Grade P0, P6, P5
Radial Clearance C0, C2, C3

 Technical Data:
Part number rule
Dimension Tolerance
Radial clearance
