Product name : MR83 bearing
Product No. : MR83 bearing 3x8x2.5mm
Details:
MR83 bearing has open, seals and shield types, and v-groove inner ring is available.
It widely used in precision instruments, micro motor, remote control model, etc industries.
| Demesions: | |
| Bearing No. | MR83, MR83-ZZ, MR83-2RS, MR83Z, MR83RS, MR83 ZZ, MR83 RS |
| Bore diameter (d) | 3mm |
| Outer diameter (D) | 8 mm |
| Width (B) | 2.5 mm |
| Basic Load Rating(N) | |
| Dynamic(Cr) | 336 |
| Static(Cor) | 113 |
| Max. Speed(RPM) | |
| Grease | 60000 |
| Oil | 67000 |
| Weight(g) | |
| Approx. | 0.51 |
| Grade | P0, P6, P5 |
| Radial Clearance | C0, C2, C3 |
Technical Data:
Part number rule
Dimension Tolerance
Radial clearance
Vibration
Grease
