Product name : 603 ZZ/RS/OPEN
Product No. : Ball Bearing 603 3x9x3mm
←[Previous Product]              [Next Product]→
Details:


603 bearing has open, seals and shield types, and v-groove inner ring is available.

These miniature bearings have greatly wide range of applied fields including Skateboard, RC Car, Dental, Fishing Reel,Yoyo, Instrument, Electric Motor, Medical and so on.

Demesions:
Bearing No. 603, 603-ZZ, 603-2RS, 603Z, 603RS, 603 ZZ, 603 RS
Bore diameter (d) 3 mm
Outer diameter (D) 9 mm
Width (B) 3 mm
Basic Load Rating(N)
Dynamic(Cr) 230
Static(Cor) 151
Max. Speed(RPM)
Grease 56000
Oil 67000
Weight(g)
Approx. 0.84
Grade P0, P6, P5
Radial Clearance C0, C2, C3

 Technical Data:
Part number rule
Dimension Tolerance
Radial clearance
Vibration
Grease
