Product name : 625 ZZ/RS/OPEN
Product No. : Ball Bearing 625 5x16x5mm
Details:
625 bearing has open, seals and shield types, and v-groove inner ring is available.
It widely used in precision instruments, micro motor, remote control model, etc industries.
| Bearing No. | 625, 625-ZZ, 625-2RS, 625Z, 625RS, 625 ZZ, 625 RS |
| Bore diameter (d) | 5 mm |
| Outer diameter (D) | 16 mm |
| Width (B) | 5 mm |
| Basic Load Rating(N) | |
| Dynamic(Cr) | 1470 |
| Static(Cor) | 540 |
| Max. Speed(RPM) | |
| Grease | 36000 |
| Oil | 43000 |
| Weight(g) | |
| Approx. | 4.95 |
| Grade | P0, P6, P5 |
| Radial Clearance | C0, C2, C3 |
Technical Data:
Part number rule
Dimension Tolerance
Radial clearance
Vibration
Grease
