Product name : R16 bearings
Product No. : R16 Bearing 25.4x50.8x9.525mm
←[Previous Product]              [Next Product]→

R16 bearing has open, seals and shield types, and v-groove inner ring is available.

It is widely used in Automotive, CNC Machinery, Textile Machinery, Washing Machine, Power Tool etc.

Bearing No. R16 R16-ZZ, R16-2RS, R16Z, R16RS, R16 ZZ, R16 RS
Bore diameter (d) 1.000inch
Outer diameter (D) 2 inch
Width (B) 0.375 inch
Basic Load Rating(N)
Dynamic(Cr) 2652
Static(Cor) 1307
Max. Speed(RPM)
Grease 9000
Oil 11000
Approx. 87
Grade P0, P6, P5
Radial Clearance C0, C2, C3

 Technical Data:
Part number rule
Dimension Tolerance
Radial clearance
