Product name : 609 ZZ/RS/OPEN
Product No. : Ball Bearing 609 9x24x7mm
Details:
609 bearing has open, seals and shield types, and v-groove inner ring is available.
It widely used in precision instruments, micro motor, remote control model, etc industries.
| Demesions: | |
| Bearing No. | 609, 609-ZZ, 609-2RS, 609Z, 609RS, 609 ZZ, 609 RS |
| Bore diameter (d) | 9 mm |
| Outer diameter (D) | 24 mm |
| Width (B) | 7 mm |
| Basic Load Rating(N) | |
| Dynamic(Cr) | 2853 |
| Static(Cor) | 1155 |
| Max. Speed(RPM) | |
| Grease | 32000 |
| Oil | 38000 |
| Weight(g) | |
| Approx. | 14.7 |
| Grade | P0, P6, P5 |
| Radial Clearance | C0, C2, C3 |
Technical Data:
Part number rule
Dimension Tolerance
Radial clearance
Vibration
Grease
